Ni-Cr-Fe Filler Metal

INCONEL Filler Metal 52 is used for gas-tungsten-arc and gas-metal-arc welding of INCONEL alloy 690. This NiCrFe welding product was developed to meet the changing needs of the nuclear industry, the higher chromium level providing greater resistance to stress-corrosion cracking in the nuclear, pure water environment. INCONEL Filler Metal 52 produces corrosion-resistant overlays on most low-alloy and stainless steels. It can also be used in applications requiring resistance to oxidizing acids. It is useful for dissimilar joints involving INCONEL and INCOLOY alloys, and carbon, low-alloy and stainless steels and for overlaying on to steel.

Specifications
AWS A5.14 ERNiCrFe-7 (UNS N06052)
ASME II, Part C, SFA-5.14, ERNiCrFe-7 (UNS N06052)
ASME IX, F-No.43
(EN) ISO 18274 – SNi6052 (NiCr30Fe9)
Supply to these specifications available upon request
For manufacture to ASME III (NCA3800, NB2400), and other specifications please refer your inquiry to the Technical Department prior to order placement.

Approvals
Please confirm details of current scope of approvals with the Technical Department
prior to order placement.

Limiting Chemical Composition
Ni+Co:	Remainder	Cr:	28.0-31.5
C:	0.04 max.	Ti:	1.0 max.
Mn:	1.0 max.	Al:	1.10 max.
Fe:	7.0-11.0	P:	0.02 max.
S:	0.015 max.	Nb+Ta:	0.10 max.
Si:	0.50 max.	Al+Ti:	1.5 max.
Mo:	0.50 max.	Others:	0.50 max.
Cu:	0.30 max.
